OEM 7Kw Electric EV Charger Wallbox Type 2 EV Home Charger Level 2

OEM 7Kw Electric EV Charger Wallbox Type 2 EV Home Charger Level 2

7Kw Electric EV Charger

OEM Electric EV Charger

Wallbox Type 2 EV Home Charger

Place of Origin:

CHINA

Brand Name:

HONGJU

Certification:

ETL,TUV,CCC,ROHS,REACH

Model Number:

HJ-EV-WE-02

Contact Us

Request A Quote
Product Details
Input Power:
100-240V; 280-440V
LCD Display:
2.8'' Color Screen
Color:
White/Black
Connector Type:
Type 2
Input Voltage:
110-240V
Installation Method:
Wall-mounted
Payment & Shipping Terms
Minimum Order Quantity
500
Price
To be negotiated
Packaging Details
Each in inner carton box, then 1 inner carton into 1 master carton
Delivery Time
30-40 days
Payment Terms
T/T
Supply Ability
100000PCS Per Month
Product Description

Electric EV Charger 7Kw OEM Wallbox EV Home Chargers Wallbox EV Charger Level 2 With Type 2 Socket



Certificates & QC
CE(UDEM lab), UKCA, ROHS,ISO;
Protection rank
IP55 Cable; IP54 Station
LCD display
2.8’’ color screen
RCD
30mA AC type A
Input power
100-240V; 280-440V
Charging cable
5M Type 2 (TPU Jacket)
Power cord
open ready to wire into electricity
Start mode
card swipe
Station size
L161 x W86 x H310 (mm)
Warranty
2 years (both cable and station)
lead time
30-35 days after deposit payment
Payment Terms
T/T(30% advanced payment ,the rest 70% balance should be paid before shippment)

Electrical Protection
Over current protection, Residual current protection, Ground protection, Surge protection
Over/Under voltage protection, Over/Under frequency protection, Over temp protection
Materials Applied
Shell: by thermoplastic PC940. Anti-corrosion and abrasion protection.
Cable: 5.0M in black with TPU jacket. With CE issued by TUV and TUV mark, UKCA, CB.
Customizing Logo
Logo put on shell by laser on station box or cable head
Package
Insides: charging station; screws; hang plates; swiping card; user manual; optional (rest socket)
Each in sponge inner tray, then in paper box, then 2 boxes into 1 master carton

Features
With Emergency stop button, and current switch, time book touch button
Product conforms to Low Voltage Directive 2014/35/EU, IEC61851-1:2019
IP54, Weather proof; Leakage current protection; Impact resistance
Charging status and working error simply displayed by LED indicators and LCD screen
Optional function of current choice button to switch current from 8A-32A / 8-16A



OEM 7Kw Electric EV Charger Wallbox Type 2 EV Home Charger Level 2 0

OEM 7Kw Electric EV Charger Wallbox Type 2 EV Home Charger Level 2 1OEM 7Kw Electric EV Charger Wallbox Type 2 EV Home Charger Level 2 2



How to make Order


Please send us an email to specify the item, quantity, color or other specification to place an order.

1. Contact us via website. e-mail. whatsapp etc contacting tools, confirm the model & quantity you want to order with us.

2. Contract will be sent to you.
3. You check the contract and make payment.
4. Package will be delivered to you once we receive the payment.



FAQ
1. What's the rated of EV Charging Cable you have?
Single phase16A / Single phase 32A / Three phase 16A / Three phase 32A
2. Can I print my own logo?
Yes MOQ 100pcs. There is no extra fee.
3. Can I customzie different color for the connector or cable?
Yes of course. MOQ 500pcs.
4. How is the warranty?
Same Q'ty good cables compensation against same Q'ty bad ones
5. How long is the lead time?
For sample order, we can ship in 2 to 5 days. For mass order, around 15 to 30 days.
6.Can I visit your company before placing the Order.
Yes. You can visit any time.
